機器型號 Machine model
|
ZJ-UA-5781D-SY-NB5
|
|
搭載機頭 Carrying nose
|
ZJ5781DS-V3
|
|
最高縫制速度 Maximum sewing speed
|
4200sti/min
|
|
鈕孔長度
Button hole length
|
≤25
|
|
切刀尺寸 Knife size
|
6.4-19.1(1/4-3/4)mm
|
|
壓腳提升高度 Presser foot lifting height
|
≤14mm
|
|
使用針 Using needles
|
DPX5
|
|
鈕孔間隔 Buttonhole spacing
|
≤610mm
|
|
鈕孔與縫料邊緣間隔 Spacing between button hole and
seam edge
|
7-21mm
|
|
最大縫料輸送距離 Maximum seam material conveying
distance
|
≤610mm
|
|
上端間隔 Upper interval
|
≤140mm
|
|
縫料寬幅 Wide width
|
220-420mm
|
|
縫料長度 length of seam material
|
480-880mm
|
|
電壓 voltage
|
220V
|
|
氣壓、空氣消費量Air pressure,air consumption
|
0.5MPa 1.8 1/min
|
|
機器重量(凈重)Machine weight(net weight)
|
353KG
|
|
機器重量(毛重)Machine weight (gross weight)
|
483KG
|
|
機器尺寸(長X寬X高)Machine size (length xwidth
xheight)
|
2220X1070X1500mm
|
|
包裝尺寸(長X寬X高) Packaging size (length xwidth
xheight)
|
2300X1100X1530mm
|
